API Time Constraint Syntax

Query API Quick Derivation

Query APIs support quick time constraints for base metrics, and also support the complete time-constraint syntax.

Quick Time Constraint Syntax

Type	Quick Syntax
Last N Days	json period__{n} [ y\|q\|m\|d\|h\|min ] * last 7 days：ordercounts__period__7d
To Date	json period__[ y\|q\|m\|w\|d\|h\|mi\|s ] t [ d\| {n}h \| {n}min \| {n}s] * year to date (day)：ordercounts__period__ytd * to date (1 second)：ordercounts__period__dts * to date (5 min)：ordercounts__period__dt5min
Current	json period__c [ y\|q\|m\|w\|d\| {n}h \| {n}min \| {n}s] * current year：ordercounts__period__cy * Current5min：ordercounts__period__c5min

General Time Constraint Syntax

{
  "metrics":[
    "order_count_7d"
  ],
  "metricDefinitions":{
    "order_count_7d":{
      "refMetric":"order_count",
      "period":"to_date -6 day of 0 day",
      "period":"",
      "specifyDimension":{
        "type":"include",
        "dimensions":"province,city"
      }
    }
  }
}

metricDefinitions

Used to generate temporary metrics. Configure the parameters as follows:

Parameter	Description
{metricname}	Name of the temporary metric. Use this metric name in the current query. json "order_count_7d":{ /* generate temporary metric order_count_7d */ "refMetric":"", "period":"", "specifyDimension":{}, }
refMetric	Base metric. Pass the metric code. If metric-name mode is enabled, pass the metric name.
period	Time constraint. See the examples below.
filter	Business filter
specifyDimension	Available dimension control

period

Time Constraint Type	Description
to_date	Last N granularities: period range * last N days, last N months json "period":"to_date -6 day of 0 day" last 7 days
grain_to_date	To date: year to date, same period from previous year to date * year to date，month to date json "period":"grain_to_date 0 day to 0 5minute" to date (5-minute granularity)
specify_date	Period start/end: special start or end date of a period * first day of this year，last day of this month json "period":" end day of -1 month" last day of last month
relative_date	Single date: one date * the day 7 days ago，last month，full current month json "period":"relative_date 0 5minute of 0 5minute" last 5 min

to_date

"period":
" to_date [Offset Count] [Offset Granularity] of 0 [Date Granularity] ",


"period":"to_date -6 day of 0 day"
last 7 days

Parameter	Description
Offset Count	Offset granularity for the current query. -N means the past N units; N means the future N units.
Offset Granularity	Supported offset granularities: * year、quarter、month、week、day、hour、nhour、minute、nminute
Date Granularity	Supported date granularities: * year、quarter、month、week、day、hour、nhour、minute、nminute

grain_to_date

"grain_to_date":
"  [Offset Count] [Offset Granularity] to 0 [Date Granularity] ",

"period":"grain_to_date 0 day to 0 5minute"
to date (5-minute granularity)

Parameter	Description
Offset Count + Offset Granularity	Offset granularity for the current query. -N means the past N units; N means the future N units.。 Supported offset granularities: * year、quarter、month、week、day、hour、nhour、minute、nminute
Date Granularity	Supported date granularities: * year、quarter、month、week、day、hour、nhour、minute、nminute

specify_date

"period":
" start|end [Date Granularity] of [Offset Count][Offset Granularity]",

"period":" end day of -1 month"
last day of last month

Parameter	Description
First or Last Within the Period
Offset Count + Offset Granularity	Offset granularity for the current query. -N means the past N units; N means the future N units.。 Supported offset granularities: * year、quarter、month、week、day、hour、nhour、minute、nminute
Date Granularity	Supported date granularities: * year、quarter、month、week、day、hour、nhour、minute、nminute

relative_date

"relative_date":
"  [Offset Count] [Offset Granularity] of 0 [Date Granularity] ",

"period":"relative_date 0 5minute of 0 5minute"
last 5 min

Integrated Query Examples

Get today’s cumulative value at 10-minute granularity

Use full definition

{
  "metrics":[
    "order_count"
  ],
  "metricDefinitions":{
    "order_count_10minute_accsum":{
      "refMetric":"order_count",
      "period":"grain_to_date 0 day to 0 10minute"
    }
  "dimensions": [
    "metric_time__10minute"
    ],
  "timeConstraint": "(['metric_time'] =  TODAY() )",
  }
}

Use quick definition

{
  "metrics":[
    "dt10mi__order_count"
  ],
  "dimensions": [
    "metric_time__10minute"
    ],
  "timeConstraint": "(['metric_time'] =  TODAY() )",
  }
}

The query result returns the following data structure.

metric_time_minute_10	order_count_10minute_accsum
2024-08-12 00:00:00	12
2024-08-12 00:10:00	18
2024-08-12 00:20:00	32
2024-08-12 00:30:00	40
...	...

Get today’s sales every 10 minutes

{
  "metrics":[
    "order_count"
  ],
  "dimensions": [
    "metric_time__10minute"
    ],
  "timeConstraint": "(['metric_time'] =  TODAY() )",
  }
}

The query result returns the following data structure.

metric_time_minute_5	order_count
2024-08-12 00:00:00	2
2024-08-12 00:10:00	4
2024-08-12 00:20:00	2
2024-08-12 00:30:00	5
...	...

Pass the current time to get the cumulative value to date

Use full definition

minute_10{
  "metrics":[
    "order_count_10minute"
  ],
  "metricDefinitions":{
    "order_count_5minute":{
      "refMetric":"order_count",
      "period":"grain_to_date 0 day to 0 day"
    }
  "dimensions": [],
  "timeConstraint": "(['metric_time'] =  NOW() )",
  }
}

Use quick definition

minute_10{
  "metrics":[
    "dt10mi__order_count"
  ],
  "dimensions": [],
  "timeConstraint": "(['metric_time'] =  NOW() )",
  }
}

The query result returns the following data structure.

order_count_10minute
4213

Pass the current time to get the metric summary for the containing 10-minute interval

Use full definition

{
  "metrics":[
    "order_count_10minute"
  ],
  "metricDefinitions":{
    "order_count_5minute":{
      "refMetric":"order_count",
      "period":"relative_date 0 10minute of 0 10minute"
    }
  "dimensions": [],
   "timeConstraint": "(['metric_time'] =  NOW() )",
  }
}

Use quick definition

{
  "metrics":[
    "c10mi__order_count"
  ],
  "dimensions": [],
   "timeConstraint": "(['metric_time'] =  NOW() )",
  }
}

The query result returns the following data structure.

order_count_10minute
420
