Get Dimension Details

API Description

Use this API to retrieve details for a specified dimension, including its display name, description, associated data type, predefined values, and value descriptions.

API URL

GET Http://{anymetrics_host:anymetrics_port}/anymetrics/api/v1/dimension/detail

To obtain anymetrics_host:anymetrics_port, see Calling APIs.

Request Parameters

Common Request Headers

Parameter	Type	Required	Description
tenant-id	String	Yes	The tenant ID of the tenant that contains the metric query assets.
auth-type	String	Yes	Authentication type. Supported values: UID, TOKEN, ACCOUNT, APIKEY.
auth-value	String	Yes	Authentication value corresponding to auth-type.
queryBy	String	No	UUID: retrieve details by dimension code.

How to Obtain Common Parameters

In Aloudata CAN, select the metric application from the top navigation bar, then choose API Integration from the left navigation menu. You can obtain tenant-id on the API Integration page. Set auth-value to the authentication value required by the selected auth-type.

Request Body

Parameter	Type	Required	Description
dimName	String	Yes	Dimension name.

Response Parameters

Response Parameter Overview

Parameter	Type	Required	Description
code	String	Yes	API response code.
success	boolean	Yes	Whether the request succeeded.
errorMsg	String	Yes	Error message.
detailErrorMsg	String	Yes	Detailed error message.
traceId	String	Yes	Trace ID for troubleshooting.
data	Object	Yes	Dimension entity.

data Parameters

Parameter	Type	Required	Description
name	String	No
dimName	String	Yes	Dimension name. - Unique within the tenant and cannot be modified. - Supports only letters, digits, and underscores. Two consecutive underscores are not supported.
dimCode	String	Yes	Dimension code.
datasetName	String	No	Dataset name.
dimDisplayName	String	Yes	Dimension display name. Supports any characters, up to 150 characters.
dimCategoryId	String	No	Dimension category ID. Use the fixed value -1 for Uncategorized. If omitted, the dimension is Uncategorized by default.
dimDescription	String	No	Dimension description. Supports any characters, up to 300 characters.
datasetName	string	Yes	Source dataset for the dimension.
originDataType	string	Yes	Original field type of the source dataset for the dimension.
config	object	Yes	Dimension source. See config Parameters.
valueList	object	No	Dimension value list. See valuelist Parameters.
basicAttributes	Map	No	Basic attributes.
businessAttributes	Map	No	Business attributes.
technicalAttributes	Map	No	Technical attributes.
managementAttributes	Map	No	Management attributes.
displayStatus	String	No	Current dimension status. Enumerated values: UNPUBLISHED: unpublished; PUBLISHED: published; SAVED_NOT_PUBLISHED: saved but not published; OFFLINE: offline; PENDING_PUBLISH: publishing; PENDING_OFFLINE: taking offline; PENDING_DELETE: pending deletion.

config Parameters

Parameter	Type	Required	Description
type	String	Yes	Dimension type, which indicates the source type. Enumerated values: - COLUMN_BIND: column binding - CUSTOM: custom type
value	String	Yes	For a column-bound dimension, set value to the column name. For a custom dimension, set value to an expression. The expression is equivalent to adding a calculated column to the dataset.

valuelist Parameters

Parameter	Type	Required	Description
value	String	No	Original dimension value. Cannot be an empty string or null.
name	String	No	Mapped name. Cannot be an empty string or null.
description	String	No	Description of the dimension value.

Request Example

{
  "dimName":"regions"
}

curl --location --request GET 'http://localhost:8083/anymetrics/api/v1/dimension/detail?dimName=dm0b1f947da9746df5bffaa57f6f0527' \
--header 'tenant-id: tn_21571046' \
--header 'auth-value: authority_test' \
--header 'auth-type: ACCOUNT' \
--header 'Content-Type: application/json' \
--header 'queryBy: UUID' \

Response Example

{
    "data": {
        "basicAttributes": null,
        "businessAttributes": null,
        "technicalAttributes": null,
        "managementAttributes": null,
        "name": "219385f66f774698b984f3b95066fb16",
        "dimName": "tb_click_1",
        "dimDisplayName": "tb_click_1",
        "dimCategoryId": "-1",
        "dimDescription": "tb_click_1 dimension update",
        "datasetName": "tb_click",
        "originDataType": "INT",
        "config": {
            "type": "COLUMN_BIND",
            "value": "user_id"
        },
        "valueList": [
            {
                "value": "Dimension value 03",
                "name": "Dimension value 03",
                "description": "Dimension value 03"
            },
            {
                "value": "Dimension value 04",
                "name": "Dimension value 04",
                "description": "Dimension value 04"
            }
        ]
    },
    "success": true,
    "code": "200",
    "errorMsg": null,
    "detailErrorMsg": null,
    "traceId": "ad3cd6c9fd5849b6a271f02f89edc93e.145.17193919044120021"
}
